32GB DDR4-2666 ECC LRDIMM
A 32GB 4Rx4 ECC load-reduced DDR4-2666 module (PC4-21300) at 1.2V, for Xeon E5-2600 v4 and the first two Xeon Scalable generations. The faster of the two DDR4 LRDIMM speed steps we regularly stock, for platforms that can use it.
Fully Tested & Documented · Hong Kong Warehouse Stock · Worldwide Shipping 3–7 Days · 1-Year Warranty
Hardware Gallery
The 32GB DDR4-2666 LRDIMM, Up Close
32GB DDR4-2666 LRDIMM - Front
Front of the module: four ranks of x4 DRAM packages with the load-reduced buffer, the design that carries this capacity on a single 288-pin DDR4 module. Photo: ITEagle Europe - Sebastiaan Broekhoven, CC BY-SA 4.0, via Wikimedia Commons (https://creativecommons.org/licenses/by-sa/4.0).
32GB DDR4-2666 LRDIMM - Rear and Label
Rear of the module with the Micron label showing the part number, the 32GB capacity and the 4Rx4 designation. That label is what we check against your order line by line. Photo: ITEagle Europe - Sebastiaan Broekhoven, CC BY-SA 4.0, via Wikimedia Commons (https://creativecommons.org/licenses/by-sa/4.0).
32GB
capacity per module, 4Rx4 organisation
2666
MT/s (PC4-21300) at 1.2V
LRDIMM
load-reduced, not interchangeable with RDIMM
Key Specifications
| Component | Specification |
|---|---|
| Form Factor | LRDIMM, 288-pin, DDR4 |
| Capacity | 32GB |
| Organisation | 4Rx4 (quad rank, x4 DRAMs) |
| Speed | DDR4-2666, PC4-21300 |
| Voltage | 1.2V (JEDEC DDR4 standard) |
| Error Correction | ECC, load-reduced |
| Intel Platforms | Xeon E5-2600 v4 (Broadwell); Xeon Scalable 1st and 2nd Gen |
| Compatibility | Requires a platform that supports LRDIMM - not interchangeable with RDIMM in the same channel |
| DRAM | Micron / Samsung / SK hynix depending on lot - confirmed at quote |
| Condition | New, or decommissioned pulls - stated line by line before you order |
| Warranty | 1 year, in writing, confirmed with the order |
2666 is the DDR4 speed step that most of the 14th generation and the first two Xeon Scalable generations actually run, which makes this the practical LRDIMM choice for those platforms rather than the 2133 part. As with any LRDIMM, the type has to be supported by the board and cannot share a channel with RDIMM. If the platform can only reach 2133, the 2133 part is the cheaper way to the same result. Full server memory range. Module photographs on this page: ITEagle Europe - Sebastiaan Broekhoven, CC BY-SA 4.0, via Wikimedia Commons.
Transparent Pricing
2026 Reference Pricing by Configuration
We do not publish a fixed price for DDR4 RDIMM or LRDIMM. DRAM contract pricing has been repricing through 2026 at a rate that makes a printed figure stale within days, so every module is quoted against the tray or pull stock we can confirm for your quantity, at the rate in force that day. If you need a number to budget against, tell us the quantity and the platform and we will put a firm figure in writing with the date it holds until.
Single Modules
On Request
Individually checked modules, new or pull condition stated before you commit. Quoted against live stock.
Matched Kits (8 or 12 DIMMs)
On Request
Full channel or socket population drawn from one lot, so a dual-socket build is not assembled from mixed batches. Tell us your platform and channel count.
Volume Orders (100+ modules)
On Request
Batch quantities consolidated from our Hong Kong warehouse, with freight and packing quoted alongside the memory.
No price is published on this page by choice rather than omission: DDR4 pricing has been moving too fast in 2026 for a static figure to be honest. Send quantity, platform and whether you need RDIMM or LRDIMM and we will quote against live stock. Related reading: server memory capacity planning and buying server CPU under memory inflation.
Origin
Hong Kong Warehouse
Free port — full export documentation
Transit
3–7 Days Air Freight
Tracked, insured, worldwide
Warranty
1-Year Warranty
Diagnostic report in every box
Quality Process
What We Check Before a 32GB DDR4-2666 LRDIMM Ships
Type Confirmed as LRDIMM
An LRDIMM shipped where an RDIMM was needed is the most expensive mistake in this part of the catalogue. The label is read and the type verified before packing.
Rank and Organisation
4Rx4 verified against the label - a quad-rank module loads the channel differently and the board has to be specified for it.
Speed Rating Checked
The 2666 rating is read from the label and the SPD rather than assumed from the part number family, because the same family ships in several speed bins.
Gold Finger and Pin Condition
Edge connector inspected under magnification for wear and bent pins before the module is accepted into stock.
Serial Logging
Serial numbers recorded per module before packing so a short or mixed shipment is traceable to the exact units dispatched.
Report in the Box
Every unit ships with its per-machine diagnostic report and warranty. Full process: inspection guide.
Frequently Asked Questions
How much does a 32GB DDR4-2666 ECC LRDIMM cost?
We quote rather than publish, because DDR4 pricing through 2026 has moved too fast for a static figure to stay accurate. Send the quantity and the platform and we will confirm condition and stock and put a firm figure in writing.
What is the difference between LRDIMM and RDIMM?
An RDIMM registers address and command signals; an LRDIMM also buffers the data lines, which is what allows four ranks and this capacity on a single module. The trade is that the two types cannot be mixed in one channel and the platform must support LRDIMM.
2666 or 2133 - which should I buy?
Buy the speed your platform actually runs. A 2666 module in a board that tops out at 2133 will simply run at 2133, so you have paid for speed you cannot use; a 2133 module in a 2666 board pins the channel to 2133. Match the module to the platform's ceiling and you spend nothing on headroom you will never see.
How much memory does 12 of these give me?
Twelve 32GB modules is 384GB, a full twelve-channel population on an EPYC or a 12-slot Xeon Scalable board. On a six-channel platform, six modules gives 192GB with the remaining slots free for later. Tell us the platform and the population you are aiming for and we will check that the ranks per channel stay within what the board supports.
Are these modules new or pulled?
Both are available and the condition is stated line by line before you order. New modules carry the manufacturer warranty process; pulls are tested and carry our own one year written warranty.
Get a 32GB DDR4-2666 LRDIMM Quote
Tell us the platform, the installed population and the quantity. We check that LRDIMM is supported on the board, then quote against live stock with the date the price holds until.
Request a Quote
